Fluid Options
Heat exchanger options suitable for water, ethylene glycol or propylene glycol. The fluid and circuit configuration are selected for the project operating conditions.
High-efficiency water-cooled cooling solution for industrial and commercial facilities with Shell&Tube and plate heat exchanger technology.
AirPlus Water Cooled Water Chiller offers Shell&Tube and plate heat exchanger technology delivering high-efficiency cooling solutions for industrial and commercial facilities. cooling tower integration provide maximum flexibility.
4-unit cascade connection, liquid injection, economizer, intercooler and equal aging scenario deliver superior performance, energy efficiency and reliability. Capable of operating with water, ethylene glycol and propylene glycol for year-round uninterrupted cooling.
High-efficiency water-cooled cooling with Shell&Tube and plate heat exchanger technology
AirPlus Water Cooled Water Chiller offers 50-1500 kW cooling capacity with scroll and screw compressor options, cooling tower integration for industrial and commercial facilities. Equipped with Shell&Tube or plate condenser/evaporator, 1/2/3/4 gas circuits, and advanced automation systems.
- Cooling Capacity
- 50 - 1500 kW
- Condenser
- Shell&Tube / Plate
- Water Circuits
- 1 / 2
- Cascade
- 4-Unit Connection
Key Features
Shell&Tube / Plate Condenser
Shell&Tube or plate type condenser. 1/2/3/4 gas circuits, 1/2 water circuits. Capable of working with water/ethylene glycol/propylene glycol. Four-way water line outlet.
Shell&Tube / Plate Evaporator
1/2/3/4 gas circuits and 1/2 water circuit options. Capable of working with water/ethylene glycol/propylene glycol, four-way water line outlet, drain valve, hot gas valve.
Cooling Tower Integration
Cooling tower connection for efficient operation even at high condenser temperatures. Winter mode cooling capability for year-round uninterrupted operation.
All Product Features
Automatic Condenser Cleaning
Automatic cleaning of condenser surfaces ensures continuous high efficiency and low energy consumption.
Evaporator and Condenser UV-C Insulation
UV-C insulation on evaporator and condenser surfaces ensures hygienic and safe operation environment.
Water Flow & Pressure Control
Evaporator and condenser water flow switch and differential pressure sensor for precise monitoring and protection.
Digital HMI Control Panel
UV-C protected digital touchscreen HMI panel with authorized user/service/administrator menu levels.
Class 2 Painted Steel Casing
Durable corrosion-resistant Class 2 painted steel casing for long service life.
Compressor Sound Enclosure
Compressor sound jacket/sound enclosure for low noise operation.
Automatic Water Filling
Automatic water filling system for operational convenience and safe operation.
Built-in Circulation Pump
Built-in circulation pump and primary circuit plate heat exchanger for compact system design.
4-Unit Cascade Connection
Cascade connection and management for up to four units for capacity flexibility and redundancy.
Liquid Injection/Economizer/Intercooler
Liquid injection, economizer and intercooler features for compressor efficiency protection and high oil temperature control.
Cooling Tower Connection
Cooling tower integration for efficient operation even at high condenser temperatures.
4-Way Water Line Outlet
Four-way water line pipe outlet on evaporator and condenser for flexible piping connections.
Water Line Dirt Trap
Water line dirt trap for system component protection and ease of maintenance.
Surface Protection Coating
Surface protection coating suitable for outdoor conditions for long-lasting durability and corrosion resistance.
Equal Aging Scenario
Equal aging algorithm on compressors and components for long service life and balanced operation.
Summer/Winter Mode Operation
Automatic summer/winter mode operation management for year-round uninterrupted operation.
Scroll and screw compressor technology
Screw or Scroll Compressor
Screw or scroll compressor option for flexible and efficient operation according to requirements.
Single/Tandem/Trio Connection
Single, tandem or trio compressor connection system for wide capacity range.
Over-Temp & Over-Current Protection
Advanced safety system protecting the compressor against over-temperature and over-current conditions.
Oil Heater and Oil Cooler
Compressor oil heater and oil cooler outlet for optimum oil temperature and long compressor life.
Condenser and evaporator features
Condenser Features
Shell&Tube or plate type. 1/2/3/4 gas circuits, 1/2 water circuits. Capable of working with water/ethylene glycol/propylene glycol. Four-way water line outlet, drain valve, hot gas valve.
Evaporator Features
Shell&Tube or plate type. 1/2/3/4 gas circuits, 1/2 water circuits. Capable of working with water/ethylene glycol/propylene glycol. Four-way water line outlet, drain valve, hot gas valve.
Refrigerant circuit standard features
Charged Refrigerant
Factory charged refrigerant for easy commissioning on site.
Electronic Expansion Valve (EEV)
Electronic expansion valve for precise refrigerant control and high efficiency.
High/Low Pressure Transmitter & Switch
Pressure transmitters and switches for continuous system monitoring and safety.
Filter Drier and Sight Glass
Filter drier and refrigerant sight glass for system control and maintenance convenience.
Liquid Line Shutoff Valve
Liquid line shutoff valve for isolation during maintenance and service operations.
Oil Balancing Line
Oil balancing line for tandem/trio compressor configurations ensuring balanced operation.
Automation and control system features
Advanced User Interface
Authorized Menu System
BMS Integration
SCADA Monitoring
Fault Logging & Tracking
Grid & Current Control
Weekly Scheduler
Operating Hours Tracking
4-Unit Cascade Management
Equal Aging Scenario
Summer/Winter Mode Mgmt
Pressure/Temp Monitoring
Water Flow & Pressure
Circulation Pump Control
Cooling Tower Control
Additional Features
Preventive Maintenance
Energy Efficiency
Ergonomic Design
Flexible Application Range
Low Operating Cost
Modular Production
Easy Installation & Compact Structure
Heat Recovery
Easy Maintenance & Service Access
User-Friendly Interface
High Sealing Performance & Durable Housing
Advanced Technology
Technical data — Models and specifications
Models and technical data
- 2-pipe / 2-pipe Plus / 4-pipe / 6-pipe configurations
- Hot-water outlet range: 90°C - 45°C
- Efficient operation at the balance point
- Evaporator and condenser UV-C insulation
- Evaporator and condenser water flow switches
- Evaporator and condenser extension pipes
- Evaporator and condenser water-line differential-pressure sensors
- Circulation-pump start/stop output
- UV-C-protected digital HMI control panel
- Class 2 painted-steel casing
- Compressor acoustic jacket or sound enclosure
- Automatic water filling
- Built-in circulation pump
- Built-in plate heat exchanger for the primary circuit
- Four-unit cascade connection
- Water-line strainer
- Liquid injection for protection of compressor efficiency
- Efficiency protection for a liquid-injection compressor
- Economizer function for protection of compressor efficiency
- High oil-temperature control using an intercooler
Technical drawings and catalogue data 1
Technical drawings and catalogue data 2
